EdgeHugger® 36-piece clamp screw assortment

EdgeHugger® 36-piece clamp screw assortment

Regular price $24.95 USD
Regular price Sale price $24.95 USD
Sale Sold out
Quantity

Features & benefits

  • The complete EdgeHugger® clamp-screw set in its own organizer box — the same screw complement included in every EdgeHugger® CNC Workholding Kit
  • Four each of nine lengths, M6-1 × 20–60 mm in 5 mm steps, covering workpiece thicknesses from 1/4" (6 mm) to 1-5/8" (42 mm)
  • The perfect companion to a clamp head 4-pack when expanding your clamping capacity
  • Compartment map on the label puts every length where you expect it
  • To find the right screw length: measure from the top of your workpiece to the bottom of the T-slot, then round up to the next 5 mm length
  • Rustproof

Included hardware (per assortment)

Description Qty Part Number
Clamp screw, M6-1 flat head, 20–60 mm (4 each of nine lengths) 36 FS0174
Organizer box, 15-compartment 1 CT0109-15

Specifications

  • ToolQuest part number: FS0174-36pc
  • Thread: M6-1, fully threaded
  • Head style: flat head, socket drive (4 mm hex)
  • Material: 18-8 stainless steel
  • Organizer box: 7" × 4" × 7/8", clear

Downloads

View full details

Included items

EdgeHugger® 36-piece clamp screw assortment Part number: FS0174-36pc
Description Qty Part number
EdgeHugger® clamp screw, M6-1 x 20 mm 4 FS0174-20mm
EdgeHugger® clamp screw, M6-1 x 25 mm 4 FS0174-25mm
EdgeHugger® clamp screw, M6-1 x 30 mm 4 FS0174-30mm
EdgeHugger® clamp screw, M6-1 x 35 mm 4 FS0174-35mm
EdgeHugger® clamp screw, M6-1 x 40 mm 4 FS0174-40mm
EdgeHugger® clamp screw, M6-1 x 45 mm 4 FS0174-45mm
EdgeHugger® clamp screw, M6-1 x 50 mm 4 FS0174-50mm
EdgeHugger® clamp screw, M6-1 x 55 mm 4 FS0174-55mm
EdgeHugger® clamp screw, M6-1 x 60 mm 4 FS0174-60mm
Screw-assortment organizer box 1 CT0109-15
